Product Parameters:
- Load Current: 80A~300A
- Resistance: 50μΩ~500μΩ
- Precision: ±0.1%~±5%
- TCR: ≤25ppm
Product Features:
- Electron beam welding Low
- Inductance ＜3nH TCR down to 10ppm/℃
- High load stability 0.02% Ideal for pulse application
- RoHS Compliant & AEC-Q200 qualified
- Automotive Grade Bare Chip Resistor/Exposed Pad Resistor
Applications:
- Power supply modules
- Industrial instrumentation
- Variable frequency drives
- Servo drive system
- Automotive Grade Bare Chip Resistor/Exposed Pad Resistor
Support custom production. Welcome to contact us for more solutions.
| Package |
Load current (A) |
Resistance (min) |
Resistance (max) |
Tolerance |
TCR (ppm"C) |
| 1620 |
80A-300A |
50μΩ |
500μΩ |
±0.1%~±5% |
≤25ppm |
| 1625 |
80A-300A |
50μΩ |
500μΩ |
±0.1%~±5% |
≤25ppm |
| 2025 |
80A-300A |
50μΩ |
500μΩ |
±0.1%~±5% |
≤25ppm |
| 7998 |
| 2530 |
80A-300A |
50μΩ |
500μΩ |
±0.1%~±5% |
≤25ppm |
